The Sports V.S.D. is a "heads up" virtual display instrument that projects the image of digital speedometer and tachometer readings onto an area of the vehicle windshield thereby to projecting virtual gauges into the driver's line of sight.
The Sports V.S.D. also provides a driver selectable display of a digital clock, elapsed trip time, trip mileage and trip countdown mileage, as well as drag race modes.
The instrument also incorporates an FLT (Fluorescent Tubing) light bar that provides an analog display in the speedometer, tachometer, elapsed trip time, trip mileage and drag race modes.
Functions:
Speed Governor Release
Speed Governor Release is applicable to the vehicles using the vehicle speed sensor signal for the speed governing function.
SP/TA MODE
The speed value is displayed digitally and the tachometer value is displayed on the FLT (Fluorescent Tubing) bar.
The speed and tachometer warning values can be set to predetermined levels. Speed warning LED(yellow) and Tachometer warning LED(red) flashes when the values reach the predetermined levels.
DRAG RACE MODE
When the 3 second countdown reaches "0.00", the unit will issue a starting signal and time measurement begins. Time measurement is displayed digitally while the driving distance to the end of a 400 meter line is displayed on the FLT(Fluorescent Tubing) bar.
Time measurement is displayed in 1/100 seconds increments.
If you take off before the countdown reaches "0.00", a buzzer sounds.
CLOCK MODE
Time is displayed from 0:00 to 12:00. The FLT (Fluorescent Tubing) bar displays the tachometer value.
ELAPSED TRIP TIME MODE
The time elapsed since the vehicle engine is started is calculated and can be displayed for intervals of up to 24 hours in 1 minute increments. The FLT ( Fluorescent Tubing) bar displays the tachometer value.
TRIP MILEAGE AND TRIP COUNTDOWN MILEAGE MODE
In this mode, trip mileage and trip mileage countdown are displayed.
Trip Mileage Mode: 0.0 to 9999 km ( 0.1 km increments )
Trip Countdown Mileage Mode : 0.0 to 9999 km (0.1 km increments)
Can be installed on 3, 4, 5, 6 and 8 cylinder vehicles with 4 cycle engines.
Display brightness is adjusted being interlocked with the illumination switch of the vehicle.
RM 550 nego
call / sms 012-2800058
