GSR Air-con Wiring Problem

[ylkien]

Hi guys,

My air-con just KO today, and after checking, i found that the wiring has melted!
Check out the photos below.

Has anyone encountered this problem before?
Is this caused by an incorrect aircon fan/compressor, which is drawing too much current?
Or is the problem with my fuse?



[spors]

we have the same problem...but mine is a cb lancer...i haven't done this yet but you can try to isolate the problem by:

1. remove the 10A fuse for the compressor then turn on ac for the fans to turn...
2. see if the wires heats up...if it does, there something wrong with the fan wirings...if it does not heat up, there's something wrong with the compressor...
