Hi all, I'm KIT Kat from Kuala Lumpur.
I'm here to see how many Voltz Rider in Malaysia & Singapore.
Any of you or your friends owned a Voltz, please keep in touch!
Lets start to register your Name, Age, Contact Number, Email, Nick of your ride & Country.
Lets meet up and form our own club - Voltz Rider Club (VZRC)
Regards!
Kit Kat
[email protected]
[email protected]
Links,
generation vibe
Generation Vibe Discussion Forums: World - Other
Voltz Specifications,
Engines
Vibe base engine
DOHC 1.8-liter inline 4-cylinder, 16 valves with VVT-I
Block material:
aluminum alloy
Displacement (cu in/cc):
109.5 / 1794
Bore & stroke (in/mm):
3.11 x 3.60 / 79.0 x 91.5
Valvetrain:
DOHC, 4 valves per cylinder
Fuel injection/delivery:
EFI
Compression Ratio:
10:1
Horsepower
130 @ 6000 (SAE net @ RPM)
AWD model:
123 @ 6000 (SAE net @ RPM)
Torque:
125 @ 4200 (lb-ft.)
AWD model:
118 @ 4200 (lb-ft.)
Fuel requirement:
87 octane
Exhaust system/emissions classification:
ULEV
Vibe GT engine
DOHC 1.8-liter inline 4-cylinder, 16 valves with VVTL-I
Block material:
aluminum alloy
Displacement (cu in/cc):
109.6 / 1796
Bore & stroke (in/mm):
3.23 x 3.35 / 82.0 x 85.0
Valvetrain:
DOHC, 4 valves per cylinder
Fuel injection/delivery:
EFI
Compression Ratio:
11.5:1
Horsepower/Kilowatts:
180/134 @ 7600 (SAE net @ RPM)
Torque:
130/176 @ 6800 (lb-ft./Nm @ RPM)
Fuel requirement:
92 octane
Exhaust system/emissions classification:
TLEV
Transmissions
Base engine:
Four-speed automatic or five-speed manual
Base engine with AWD:
Four-speed automatic
GT engine:
Six-speed manual
Chassis/Suspension
Front suspension:
MacPherson strut with coil springs and stabilizer bar
Rear suspension:
FWD
torsion beam with trailing link, coil springs and stabilizer bar
AWD
independent double wishbone with coil springs and stabilizer bar
Steering:
Power-assisted rack-and-pinion
Ratio:
19.5:1
Wheel turns, lock to lock:
3.36 (AWD 3.38)
Turning diameter, curb to curb (ft/m):
36.7/11.2
Brakes
Base:
10.8-inch (275 mm) front discs / 8.98-inch (228 mm) rear drums
AWD:
10.8-inch (275 mm) front discs / 8.98-inch (228 mm) rear drums
GT:
four-wheel discs, 10.8-inch (275 mm) front / 10.6-inch (269 mm) rear
Wheels/Tires
Wheels:
16-inch aluminum/steel
17-inch aluminum
Tires:
P205/55R/16-all-season
I'm here to see how many Voltz Rider in Malaysia & Singapore.
Any of you or your friends owned a Voltz, please keep in touch!
Lets start to register your Name, Age, Contact Number, Email, Nick of your ride & Country.
Lets meet up and form our own club - Voltz Rider Club (VZRC)
Regards!
Kit Kat
[email protected]
[email protected]
Links,
generation vibe
Generation Vibe Discussion Forums: World - Other
Voltz Specifications,
Engines
Vibe base engine
DOHC 1.8-liter inline 4-cylinder, 16 valves with VVT-I
Block material:
aluminum alloy
Displacement (cu in/cc):
109.5 / 1794
Bore & stroke (in/mm):
3.11 x 3.60 / 79.0 x 91.5
Valvetrain:
DOHC, 4 valves per cylinder
Fuel injection/delivery:
EFI
Compression Ratio:
10:1
Horsepower
130 @ 6000 (SAE net @ RPM)
AWD model:
123 @ 6000 (SAE net @ RPM)
Torque:
125 @ 4200 (lb-ft.)
AWD model:
118 @ 4200 (lb-ft.)
Fuel requirement:
87 octane
Exhaust system/emissions classification:
ULEV
Vibe GT engine
DOHC 1.8-liter inline 4-cylinder, 16 valves with VVTL-I
Block material:
aluminum alloy
Displacement (cu in/cc):
109.6 / 1796
Bore & stroke (in/mm):
3.23 x 3.35 / 82.0 x 85.0
Valvetrain:
DOHC, 4 valves per cylinder
Fuel injection/delivery:
EFI
Compression Ratio:
11.5:1
Horsepower/Kilowatts:
180/134 @ 7600 (SAE net @ RPM)
Torque:
130/176 @ 6800 (lb-ft./Nm @ RPM)
Fuel requirement:
92 octane
Exhaust system/emissions classification:
TLEV
Transmissions
Base engine:
Four-speed automatic or five-speed manual
Base engine with AWD:
Four-speed automatic
GT engine:
Six-speed manual
Chassis/Suspension
Front suspension:
MacPherson strut with coil springs and stabilizer bar
Rear suspension:
FWD
torsion beam with trailing link, coil springs and stabilizer bar
AWD
independent double wishbone with coil springs and stabilizer bar
Steering:
Power-assisted rack-and-pinion
Ratio:
19.5:1
Wheel turns, lock to lock:
3.36 (AWD 3.38)
Turning diameter, curb to curb (ft/m):
36.7/11.2
Brakes
Base:
10.8-inch (275 mm) front discs / 8.98-inch (228 mm) rear drums
AWD:
10.8-inch (275 mm) front discs / 8.98-inch (228 mm) rear drums
GT:
four-wheel discs, 10.8-inch (275 mm) front / 10.6-inch (269 mm) rear
Wheels/Tires
Wheels:
16-inch aluminum/steel
17-inch aluminum
Tires:
P205/55R/16-all-season
