JASMA Racing Connecting Rod (CONROD)

JASMA RACING CONNECTING ROD

H-BEAM, I-BEAM, A-BEAM & X-BEAM
FORGED 4340 CHROME MOLY STEEL ROD


JASMA® Toyota 3S-GE & 3S-GTE H-beam con rod model 31068 ......RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® SR20 Series H-beam con rod model 31057 ......RM920
Price Quoted For 4 pcs with 8740 bolts


JASMA® Kelisa/Kenari H-beam con rod
model 31071.................................................................RM690
Price Quoted For 3 pcs with 8740 bolts Note : 3pcs


JASMA ® Kelisa/Kenari L9 & L7 H-beam con rod
model 31118..................................................................RM920
Price Quoted For 4 pcs with 8740 bolts


JASMA® Campro 1.3 H-beam con rod
model 31069..................................................................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® Subaru EJ18, EJ20, EJ22 & EJ257
( WRX STi ) H-beam con rod model 31072...................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G15 H-Beam con rod model 31073...............RM920
Price Quoted For 4 pcs with 8740 bolts


JASMA® 4G93 pin size 21mm H-Beam con
rod model 31048............................................................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G93 pin size 19mm H-Beam con
rod model 31051............................................................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G93 GSR, Mazda B6/B8, CA18
pin 20mm H-Beam con rod model 31056.......................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G91/4G92 SOHC/DOHC H-beam
con rod model 31070.......................................................RM920
Price Quoted For 4 pcs with 8740 bolts
Center to Center Shorten By 2.7mm. Lower Compression



JASMA® 4G63 VR4 1st Generation pin size 21mm
H-Beam con rod model 31055.........................................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G63 2nd Generation evo 1-9
pin size 22mm I-Beam con rod model 31050.................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G63 2nd Generation Evo 1-9
pin size 22mm X-Beam con rod model 31062................RM920
Price Quoted For 4 pcs with 8740 bolts
Note : For Extreme Power ( Heavy Duty )

JASMA® 4G63 2nd Generation Evo 1-9
pin size 22mm H-Beam con rod model 31074.................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® 4G63 Combo pin size 22mm H-Beam
con rod model 31049.........................................................RM920
Price Quoted For 4 pcs with 8740 bolts
( 2nd Generation Piston on 1st Generation Crank
or 2nd Generation Stroker Piston on 4G64 Crank )
1st Generation = VR4
2nd Generation = EVO

JASMA® B16A H-Beam con rod model 31054....................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® B16A I-Beam con rod model 31063...................RM990
Price Quoted For 4 pcs with 8740 bolts

JASMA® B18A/B & B20B/Z H-Beam con rod
model 31052........................................................................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® B18A/B & B20B/Z I-Beam con rod
model 31065........................................................................RM990
Price Quoted For 4 pcs with 8740 bolts

JASMA® B16B H-beam con rod model 31061.....................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® K20A I-Beam con rod model 31066...................RM990
Price Quoted For 4 pcs with 8740 bolts

JASMA® K20A A-Beam con rod model 31067...................RM990
Price Quoted For 4 pcs with 8740 bolts

JASMA® B18C H-Beam con rod model 31053....................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® H22 H-beam con rod model 31047.......................RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® Toyota 4E(1000cc) L2/L6/L7/L9 H-Beam con rod model 31058.............RM690
ANY EJ ENGINE CODE WITH 1000CC BLOCK
THIS CANNOT FIT [ JB ]ENGINE CODE
CANNOT USE ON KENARI /KELISA ENGINRE
Price Quoted For 3 pcs Note : 3pcs
Note : Can Use For L2 Head With Kelisa block

JASMA ® Toyota 4E H-Beam con rod model 31119............RM920
Price Quoted For 4 pcs with 8740 bolts

JASMA® Toyota 4E I-Beam con rod model 31059............RM740
Price Quoted For 3 pcs Note : 3pcs
Center to Center Shorten By 0.7mm Lower Compression

JASMA® 4AG H-beam con rod model 31060.....................RM920
Price Quoted For 4 pcs with 8740 bolts
Note :
C-to-C Length : 122mm
Big End Diameter : 43
Pin End Diameter : 20mm Original Pin End Diameter is 18mm
Pin End Width : 21.85mm
Big End Width : 21.85mm


#Note : Made In Taiwan , From The Same Factory That Supply To The Big Company In South American.
Just To Name A Few Like Pro-Comp, Scats, Arrow & Nitto In Australia.


Rods Features:
- Material: Precision forged 4340 EN24 aircraft chrome moly quality
steel.
- Hardness after quenching and tempering is HRC35-38.
- 3-D design offers the advantages of reduced weight without
sacrificing strength.
- 2 piece forging for increased strength.
- Silicon bronze bushings for floating piston pins.
- Each forging is X-rayed, sonic tested and magnafluxed.
- Special Dowelled Cap for precision alignment.
- Shot peened to relieve stress.
- Fully CNC machined on all surfaces to produce the lightest and
strongest rod.
- Forged Billet 4340 aircraft quality steel

Machining Tolerances:
Big End and Small End Tolerance: -0.00017"
Verticality, Parallelism and Distortion: -0.00018"
Center to Center Distance Tolerance: -0.001"
Sets weight matched to +/-1 gram.

# Visit our showroom at Pandan Indah.

- Price are without installation.

Payment method: bankin/cash/credit card/paypal/online transfer/atm transfer/ western union
Dealing method: COD/Poslaju/Parcel sevice
Location : 22M,Mezzanine Floor, Jalan Pandan Indah 1/23A, 55100, Pandan Indah, KL
Proof : Will provide a offical receipt
Working Hour: 11AM-9PM (monday to saturday)

Contact No:016-3234991/0146401073/03-92268921

www.topsoundperformance.com
www.topsoundperformance.blogspot.com



[topsound]

BUMP!!!!!!!
http://www.topsoundperformance.com/ for more product
PAGE STILL IN UPDATING PROGRESS



[nomo5]

JASMA® 4AG H-beam con rod model 31060.....................RM920
Price Quoted For 4 pcs with 8740 bolts
Note :
C-to-C Length : 122mm
Big End Diameter : 43
Pin End Diameter : 20mm Original Pin End Diameter is 18mm
Pin End Width : 21.85mm
Big End Width : 21.85mm

can use to kelisa 1000cc engine?



[topsound]

Bump!!!!!!!!!!



[lucankong82]

JASMA® Kelisa/Kenari H-beam con rod
model 31071............................................. ....................RM690
Price Quoted For 3 pcs with 8740 bolts Note : 3pcs


JASMA ® Kelisa/Kenari L9 & L7 H-beam con rod
model 31118............................................. .....................RM920
Price Quoted For 4 pcs with 8740 bolts


JASMA® Toyota 4E(1000cc) L2/L6/L7/L9 H-Beam con rod model 31058.............RM690
ANY EJ ENGINE CODE WITH 1000CC BLOCK
THIS CANNOT FIT [ JB ]ENGINE CODE
CANNOT USE ON KENARI /KELISA ENGINRE
Price Quoted For 3 pcs Note : 3pcs
Note : Can Use For L2 Head With Kelisa block

Hi can u advice whats the difference between the 3 prices items above?
Why do you have so many different model for same engine such as 31058,31118,31071?
If I plan to BOT EJDE Kelisa original engine, which should be the choice and why?
What's the rated safe HP can the con rod be safe for?
It's plug and play without modification?

Thakn you for the advice.
