Driving the Vios Challenge race car last Thursday gave me yet another lesson in circuit driving. This compact cup car also solidified the fact that low powered cars are as, if not more demanding than fast cars on the circuit. Also, at the end of this post, I've highlighted some driving aspects that I feel compelled to share with you.



But in any case, having acquainted myself with the Vios racecar I can now say for sure the actual street race event will be an exciting one. The fights will be close and there will be hard contact among the competition. Like the below video:

I really can't wait to see the 40 car grid this coming August in Penang. It's been too long we've not had a street race like that and last weekend's Bangsaen race just made the craving even worse.

<iframe class="instagram-media instagram-media-rendered" id="instagram-embed-0" src="https://www.instagram.com/p/BWSgk1zjLHt/embed/captioned/?cr=1&v=7&wp=658#%7B%22ci%22%3A0%2C%22os%22%3A17483.645%7D" allowtransparency="true" data-instgrm-payload-id="instagram-media-payload-0" scrolling="no" style="background: rgb(255, 255, 255) none repeat scroll 0% 0%; border: 1px solid rgb(219, 219, 219); margin: 1px 1px 12px; max-width: 658px; width: calc(100% - 2px); border-radius: 4px; box-shadow: none; display: block; padding: 0px;" height="567" frameborder="0"></iframe> <script async="" defer="" src="//platform.instagram.com/en_US/embeds.js"></script>
<script async="" defer="" src="//platform.instagram.com/en_US/embeds.js"></script>


The First drive in a Vios Racecar


I've been eyeing to drive the race Vios since its inception in April. There's just something about cup cars that excite drivers. Perhaps because it is the perfect benchmark to measure where one ranks in the arena of driving and even more so when the Vios is such a relatable car to many of us. Long story short, just last week I was offered the privilege to sample the famed Toyota racer and needless to say, I was more than thrilled.

Set at Sepang Circuit's new South side, UMW Toyota has prepared 10 cup cars for this test day. These are identically specced touring race cars made specifically for the impending Vios Challenge 2017 in August, presented by Toyota Gazoo Racing Malaysia.



Toyota Gazoo Racing


The name Gazoo is literally made up of "garage" and "zoo". It was created in 2015 when Toyota decided to consolidate a huge chunk of their racing efforts under 1 roof. Gazoo Racing is a combination of race teams that can be seen competing in top tier motorsport event such as the WEC, WRC, Nürburgring 24 Hours Endurance Race, Dakar Rally and NASCAR. http://toyotagazooracingmalaysia.com.my/




TRD & Vios Challenge

TRD, the renowned motorsport arm of Toyota provides support to Gazoo Racing in their every activity whether it is engineering or expertise and it's no different with the Vios Challenge. Significant areas of the Vios Challenge were influenced by TRD such as the overall race operation, racecar development and even in street circuit design and so on.



The Vios Race Car


These Vios cup cars begin life as a regular, brand new, manual Toyota Vios 1.5J that were assembled in Shah Alam. It is then stripped and caged, while retaining factory stock essentials such as the ecu, wiring, dashboard, (cut to fit cage then reinstalled) even the shift knob and foot pedals are stock (except for the aftermarket Works Engineering throttle pedal plate).



Performance wise, the 107hp / 140nm 1.5L Dual VVTI engine is left stock but breathes through a TRD exhaust. Other notable performance upgrades are the TRD specced clutch and TRD LSD.

In its chassis, the Vios receive TRD's suspension system as well as a further increase in rigidity with a TRD front tower and lower brace bars. Enkei RPF1 wheels and uprated brake pads complete this area. Tyres are strictly Toyo T1R rubbers, adhering to Toyota Gazoo Racing's controlled tyre regulations.



The Race Package


If you didn't already know, the Vios Challenge racing event is open to the public and I don't just mean to spectate but to actually race in the Vios racecar. All you need is to purchase the package and possess a valid AAM racing license, which only require a fee and an application.

The Vios Challenge 2017 Launch and Program Details:
ttp://www.zerotohundred.com/2017/vios-challenge-toyota-gazoo-racing-festival-now-in-malaysia/

To keep up with high demand, just 2 weeks ago, Toyota Gazoo Racing even added 10 additional cars on top of the initial 30 bringing the total grid to 40 cars. I heard there is 3 more slots left, so if you're interested, apply now as the inaugural race is only weeks away. The TGR Festival is a huge weekend long carnival that will tour Penang, Johor and twice in KL.



Here's what the RM90K package includes:

- Toyota Vios Race Car
- Race Engineering
- Race car testing sessions
- FIA approved race suits
- 6 sessions of racing school training
- TRD aerodynamic kit
- TRD exhaust system
- TRD clutch and LSD
- TRD suspension system
- TRD tower and lower brace bars
- Uprated brake pads
- Rollcage
- Enkei wheels
- Toyo T1R tyres



All race conversion and the entire race engineering side of the Vios Challenge is contracted exclusively to Wing Hin Motorsports. They've done an excellent job at transforming the cars.

My Experience with Wing Motorsports for MMER 12hr

http://www.zerotohundred.com/2014/the-experience-wing-hin-motorsports-86-race-car-at-sepang-on-board-drive-videos/


Wing Hin Motorsports


Wing Hin Motorsports is the motorsport arm of Wing Hin, an entity known for their attention to detail, a Toyota loyalist, TRD dealer, and is one of the largest Toyota vehicles dealer in Malaysia. They also field the best pair of Toyota 86 touring cars which I had the extreme privilege to race in and finish at the MMER 12 Hours 2014.

Wing Hin Motorsports has made a huge influence in my life since. It was the most amazing experience preparing for the 12 hour race. The many weekends where we spent practicing pit stops before the super elaborate pit setup during race weekend. They are very meticulous. I've seen how passionate the entire team can be when motorsport is in operation. However when not in operation, these guys serve as senior managers, engineers, technicians at Wing Hin Automobiles.


The First 10 cars


Certain items seen here are only featured in the first 10 car batch, such as the Motec race dash, onboard video equipment, etc. Also, the first 10 gets a pair of OMP bucket seats. These first 10 are Toyota Gazoo Racing's first batch of cup Vios cups cars which were used for promotional activities and driver coaching prior to the actual race event.



Vios Challenge Celebrity Drivers:

Also, out of the 10 cars, 8 will be celebrity driven. They are made of social figures possessing anywhere from 5 to 7 figure social followers, be it on Facebook, Instagram or YouTube. These guys range from popular Key Opinion Leaders to models to beat boxing master Shawn Lee to Astro artiste Danny Koo.

- Danny Khoo
- Shawn Lee
- Geraldine Gan
- Venice Min
- Shukri Yahaya
- Fattah Amin
- Diana Danielle
- Janna Nick



Verdict


Throughout my experience driving or racing in Sepang, I have only set foot in either full on racecars or road cars, but never in a 100-odd hp 1.5L spec series racecar like the Vios. Let's face it, there's about 100hp less in here than other cars i've had the pleasure of driving in Sepang so yes, the Vios is not jaw-droppingly fast. It's a fact.

But power isn't always the point. A race is a race, no matter the platform or car. it's the vying for top position against the competition, it's doing your best despite whatever handicap you may have. In this case, it's coming on top in a single-make, single-spec cup race, fair and square, driven by the motivation to win and above all, skills.

<iframe width="700" height="415" src="https://www.youtube.com/embed/QJq6HSPiqlQ?list=PLmcj9BeTWyjisj-HFUOtDrTgL_mZenRbI" frameborder="0" allowfullscreen></iframe>

Because the Vios Challenge platform is literally an entry level one make series, this means the car must remain as factory form as possible, such as the factory specced engine and basic changes to facilitate driver safety and racing abuse.



With about 110hp at my disposal (judging from the TRD exhaust upgrade) and road-use Toyo T1-R tyres on the south circuit half of Sepang, I managed my best lap times of mid 1:26s, which was pretty decent when based against the current test session lap times by other seasoned drivers.

However, it did require a handful of laps before I arrive at the stated lap times. It was a matter of learning the Vios and mostly trying to find ways not to lose precious speed, be it when braking for or exiting out of a corner. The Vios is inherently lightweight in the power department, so speed takes effort to build. Any miscalculated judgement or gesture can cause a large speed drop, which will impact lap times significantly.



Also, the Toyo T1-R tyre being road specced performance tyre has its own limits. Enter a corner too fast and the Vios will incur the dreaded understeer and subsequently scrub speed.

So, to clock a good lap, it was imperative to drive the Vios as cleanly and gracefully as possible. Changing my driving style to fully optimise available power and grip the car had. This meant precise braking without shedding too much speed while being able to power out as soon as possible, for example, in turns such T11 or T14. It's quite a challenge at first, but was well worth it.

Check out http://toyotagazooracingmalaysia.com.my to know more about the upcoming TGR street races coming to a town near you







Attachments

RENESIS VIII

7,000 RPM
Senior Member

RENESIS VIII

7,000 RPM
Senior Member
Jun 13, 2012
7,060
948
713
Ipoh
Looks like this new 2NR-FE eco friendly engine is capable on its own. I wonder how it fares against the older 1NZ-FE where quite many people had modded that one.


Tom

TIMETOATTACK
Helmet Clan

Tom

TIMETOATTACK
Helmet Clan
Jul 6, 2000
5,450
3,156
5,213
Kuala Lumpur
Event in Penang. I sure be there if not clash with my work.
it'll be weekend long so you're probably going to make it since you're based in Penang

Looks like this new 2NR-FE eco friendly engine is capable on its own. I wonder how it fares against the older 1NZ-FE where quite many people had modded that one.
can't tell the difference since it's a circuit drive, also it's my first drive in a manual Vios. Feels good to be honest, although pace wise, there isn't much to shout about especially when driven on the huge circuit. On the other hand, I think a manual Vios can be a great daily car


RENESIS VIII

7,000 RPM
Senior Member

RENESIS VIII

7,000 RPM
Senior Member
Jun 13, 2012
7,060
948
713
Ipoh
it'll be weekend long so you're probably going to make it since you're based in Penang



can't tell the difference since it's a circuit drive, also it's my first drive in a manual Vios. Feels good to be honest, although pace wise, there isn't much to shout about especially when driven on the huge circuit. On the other hand, I think a manual Vios can be a great daily car
Well, on paper, I think the new 2NR-FE engine produce 1hp lower than the older 1NZ-FE. Maybe just a difference like between aircond on and aircond off.

I believe that a manual Vios is good enough for short sprints and acceleration in city areas.


Tom

TIMETOATTACK
Helmet Clan

Tom

TIMETOATTACK
Helmet Clan
Jul 6, 2000
5,450
3,156
5,213
Kuala Lumpur
Well, on paper, I think the new 2NR-FE engine produce 1hp lower than the older 1NZ-FE. Maybe just a difference like between aircond on and aircond off.

I believe that a manual Vios is good enough for short sprints and acceleration in city areas.
great runabout and generally a fun car to have definitely


RENESIS VIII

7,000 RPM
Senior Member

RENESIS VIII

7,000 RPM
Senior Member
Jun 13, 2012
7,060
948
713
Ipoh
great runabout and generally a fun car to have definitely
I agree with you. For that segment, it seems like Vios is the winner due to the lack of manual option in our market. Almera manual probably can't compare with Vios. City, Jazz, Mazda 2 are not available in manual here. :banghead:


vr2turbo

Beyond 20,000 RPM!
Helmet Clan
Moderator

vr2turbo

Beyond 20,000 RPM!
Helmet Clan
Moderator
May 11, 2010
29,589
8,263
1,713
Petaling Jaya
I agree with you. For that segment, it seems like Vios is the winner due to the lack of manual option in our market. Almera manual probably can't compare with Vios. City, Jazz, Mazda 2 are not available in manual here. :banghead:
See Tom and Kon in youtube with autobuzz on manual transmission....:driver:


Tom

TIMETOATTACK
Helmet Clan

Tom

TIMETOATTACK
Helmet Clan
Jul 6, 2000
5,450
3,156
5,213
Kuala Lumpur
I agree with you. For that segment, it seems like Vios is the winner due to the lack of manual option in our market. Almera manual probably can't compare with Vios. City, Jazz, Mazda 2 are not available in manual here. :banghead:
good point, didn't really think only the Vios would be the only choice here

just did a search and found:

VIOS 1.5 TRD SPORTIVO (AT) From RM 93,600.00
VIOS 1.5GX (AT) From RM 90,020.00
VIOS 1.5G (AT) From RM 87,100.00
VIOS 1.5E (AT) From RM 81,400.00
VIOS 1.5J (AT) From RM 77,400.00
VIOS 1.5J (MT) From RM 74,160.00

75K for a no frills sedan in manual sounds pretty decent


sweelt

2,000 RPM

sweelt

2,000 RPM
Nov 6, 2016
2,262
231
163
Penang
See Tom and Kon in youtube with autobuzz on manual transmission....:driver:
Ya, that video. Manual trans is preferred. But in future is like " not much know how to play "guli @ marbles" "
As long there's willing to teach and learn. This shift stick skill wont extinct.
One interesting point, not many thief know to drive stick.

Last edited:

RENESIS VIII

7,000 RPM
Senior Member

RENESIS VIII

7,000 RPM
Senior Member
Jun 13, 2012
7,060
948
713
Ipoh
See Tom and Kon in youtube with autobuzz on manual transmission....:driver:
Will go and watch it now.

good point, didn't really think only the Vios would be the only choice here

just did a search and found:

VIOS 1.5 TRD SPORTIVO (AT) From RM 93,600.00
VIOS 1.5GX (AT) From RM 90,020.00
VIOS 1.5G (AT) From RM 87,100.00
VIOS 1.5E (AT) From RM 81,400.00
VIOS 1.5J (AT) From RM 77,400.00
VIOS 1.5J (MT) From RM 74,160.00

75K for a no frills sedan in manual sounds pretty decent
From a testing video that I watched at Youtube recently, someone took his 3rd gen Vios manual (1NZ-FE) and did a drag race with Civic FD 1.8 auto. The result is, the Civic totally cannot keep up with Vios despite having a 300cc advantage in displacement.

If this Vios challenge thing is a success, I hope it will make other car distributors consider bringing in manual transmission option. Actually, a Jazz or City with manual transmission can probably sell over here since there are a lot of Honda fans over here.

Last edited:

RENESIS VIII

7,000 RPM
Senior Member

RENESIS VIII

7,000 RPM
Senior Member
Jun 13, 2012
7,060
948
713
Ipoh
Watched it till the end. A very good discussion from Tom and Kon.

The traffic crawling thing that Tom mentioned is very true. I'm driving manual most of the time and only ever driven auto in my housing area using my mother's car. When it comes to low speed movements, I find it hard to adjust in automatic as I need to rely a lot on the brakes to control the speed when I am parking. With manual, I can just control using the clutch and that is way easier compared to auto.

As for moving the car from slope or hill, I don't feel like it is much of a challenge anymore nowadays. Is like a natural reaction where I'll release the clutch pedal slightly faster and press more on the throttle to move the car smoothly without roll back.

I guess I am considered as the odd one among a sea of younger generations that is not interested in driving manual anymore. I am 24 this year and I think I am part of those younger generations that they mentioned in the video.

If only modern cars here can be had with such a spec, I would really consider getting something like this Mazda 3 in future. But for now, most affordable range of new cars in the market does not really interest me. Here is a video of it.
